Feature
A wide manufacturing range of Bourdon tube pressure gauges meeting JIS.B7505 standard, including pressure gauge, vacuum gauge and compound gauge, are available.
Spec
| Size |
φ60
φ75
φ100
φ150
φ200 |
| Shape of casing |
Standard case, Closed case
Type A
Type B
Type D (front rim or middle rim) |
| Connecting thread |
φ60…R1/4 (G1/4)
φ75…G3/8
φ100…G3/8, G1/2
φ150…G3/8, G1/2
φ200…G1/2 |
| Materials for the parts touching liquid |
(differs according to pressure)
*General Use
socket:C3604BD, YBSC3
bourdon tube:C2700T, SCM435,
SUS316
*Corrosion Resistant application(for ammonia)
socket:SUS316
bourdon:SUS316 |
| Pressure range |
Pressure gauge
0～100MPa
（φ60：to 25MPa,
φ75：to 60MPa）
〔0～1000kg/c㎡
（φ60 to 250kg/c㎡,
φ75 to 600kg/c㎡）〕
Vacuum gauge
-0.1～0MPa
（76cmHg～0cmHg）
Compound gauge
-0.1～2.5MPa
（76cmHg～25kg/c㎡） |
| Classification（mark） |
Ordinary type for steam（M）
Heatproof type（H）
Vibration-proof type（V）
Vibration-proof type for steam（MV）
Heat and vibration proof type（HV） |
| Accuracy |
±1.6％F.S. |
|
φ100/Type B
|
φ100/Type A
|
Adjustable red pointer
|
φ150/Type B
|
φ100/Type DF（Front rim）
|
|
